NEW

8K SSD Recorder

Product ID: HR-7518 / HR-7518-A

HR-7518 is a 2U stand-alone 8K SSD recorder supporting both compressed and uncompressed recording and playback.

Features

・Supports compressed recording and playback of 8K Dual Green, full-resolution 8K and full-specification 8K* with one unit
(*HR-7518-A only)
・Supports compressed recording using Grass Valley HQX Codec
・Installation of USB 3.0 port provides more convenient 8K data transferring experience (10GbE to be supported in the future)
・Maximum capability for recordings are as listed below:
Uncompressed: 48 min(4TB SSD Pack × 2 units)/ Compressed: 80 min(HQX 8:1)
・U-SDI(ARIB STD-B58) ,3G-SDI and 12G-SDI are installed for input/output interfaces
・2 SSD packs can be installed. Packs can be swapped during recording or playback with the exception of some recording formats.

・2 available options for SSD packs.
・2TB(Model:MM-210)/ 4TB(Model:MM-210-A)
・Maximum 32ch audio recording(uncompressed with 24 bit)available

Specifications

Item

Specifications

Video Format

8K(7680×4320) Dual Green 59.94p 8K YCBCR 4:2:2 59.94p 8K RGB 4:4:4 59.94p 8K YCBCR 4:2:2 119.88p 8K RGB 4:4:4 119.88p

Video Input

3G-SDI (SMPTE 424M/ST 425-1) 8 sets 12G-SDI (SMPTE ST 2082-12) 4 sets #3G/12G switchable by selection. Ancillary data (audio and TC) supported Optical (ARIB STD-B58) 1 set Ancillary data (audio and TC) supported

Video Output

3G-SDI (SMPTE 424M/ST 425-1) 8 sets 12G-SDI (SMPTE ST 2082-12) 4 sets distributed Ancillary data (audio and TC) supported Optical (ARIB STD-B58) 1 set Ancillary data (audio and TC) supported

HD OUT

HD-SDI(SMPTE 292M)1ch-2 splits 1920x1080 59.94i Embedded Audio, Time Code, Character.

Reference Input

HD tri levels or BB Signals 75Ω BNC Passive Through

MADI IN/OUT (Multichannel Audio Digital Interface)

75Ω BNC 1ch

Timecode IN/OUT

BNC 1ch Supports only LTC

RS-422

D-Sub 9pin (Female)、SONY Protocol

GPIO

D-Sub 15pin (Female) for TALLY/ALARM, /REC ON/OFF

USB 3.0

Type B Connector for Communicating with PC

USB 2.0

Type A Connector for Communicating with Memory drive

Audio IN

XLR 3pin Female Connector, Stereo Channels, LINE/MIC/MIC+48V INPUT

SD Slot

SD Card Slot for updating firmware and log taking

Headphone

3.5mm Stereo mini jack

[ General Specification ]

Power Voltage

AC100 - 240V

Operating Temperature

0 - 40°

Operating Humidity

20~80%RH(no condensation)

Power Consumption

150W (Estimated)

Dimensions

2U Rackmount size: 430(W) × 88(H) × 350(D) mm(excluding protrusions)

Weight

Approx. 8.2 kg(excluding SSD packs)

[ Recording Time ]

Video Format

Recording Time

Uncompressed

HQX 8:1

SSD Type

2TB x 2

4TB x 2

2TB

4TB

8K Dual Green 59.94p

20 min *1

40 min *1

40min

80min

8K YCBCR 4:2:2 59.94p

-

-

40min

80min

8K RGB 4:4:4 59.94p *2

-

-

40min

80min

8K YCBCR 4:2:2 119.88p

-

-

20min

40min

8K RGB 4:4:4 119.88p *2

-

-

20min

40min

*1 : Parallel two SSD pack recording is necessary for uncompressed data *2 : Will convert to YCBCR 4:2:2 before encoding

[ SSD Packs(Option) ]

2TB Model:MM-210 4TB Model:MM-210-A

Dimensions

138(W) × 92(H) × 18(D) mm (excluding protrusions)

Weight

Approx. 0.4 kg

[ Outputting File Format ]

Item

Specifications

HQX AVI

Compressed Video Container(HQX)

DPX

Uncompressed Video Container RGB 10bit

DG-RAW

Dual Green SHV Raw Data Container

WAV

Uncompressed Audio Stereo 24bit

[ Accessories(HR-7518) ]

Name

Quantity

HR-7518

1

AC Cable

2

HR-7518 Instructional Manual

1

Data Transferring Software(CD-ROM)

1

EIA2U Rackmount Clamp

1
